TRANSMISSION SYSTEM ASSEMBLY (WIDE VEHICLE VERSION)

TRANSMISSION SYSTEM ASSEMBLY (WIDE VEHICLE VERSION)

#

Item Name

Price

Qty

1

FR CV DRIVE SHAFT ASSEMBLY(WIDE )

S03P12000001

$326.69

2

FL&FR OUTER CV BOOT ASSEMBLY

S01P11002001

$136.50

3

FL&FR OUTER CV BOOT DUST COVER ASSEMBLY

S01P11005001

$48.23

3.1

SMALL CLAMPING BAND

U01P11004001

$2.73

3.2

BIG CLAMPING BAND

U01P11002001

$4.55

4

FRONT RIGHT MIDDLE SHAFT

S03P12002001

$81.90

5

FL&FR INNER CV BOOT DUST COVER ASSEMBLY

S01P11004001

$48.23

5.1

BIG CLAMPING BAND (2)

U01P11008001

$3.64

5.2

SMALL CLAMPING BAND (2)

U01P11006001

$2.73

6

FRONT RIGHT INNER CV BOOT ASSEMBLY

S01P12001001

$129.22

6.1

CIRCLIP

U01P11011001

$2.73

7

FL CV DRIVE SHAFT ASSEMBLY(WIDE)

S03P11000001

$327.60

8

FRONT LEFT MIDDLE SHAFT

S03P11003001

$81.90

9

FRONT LEFT INNER CV BOOT ASSEMBLY

S01P11001001

$129.22

10

BOLTS M8X35

A03F11001101

$0.91

11

FRONT DRIVE SHAFT FRONT SECTION ASSEMBLY

S03P21100002

$304.85

11.1

TRANSMISSION SHAFT MOUNTING SPLINE FORK

U01P21101001

$65.52

11.2

CIRCLIP 25

GBT000893007

$2.73

11.3

UNIVERRSAL CROSS SHAFT ASSY

U01P22010001

$50.05

11.4

FUEL CUP M6

GBT001152001

$0.91

11.5

TRANSMISSION SHAFT SLIDING SPLINE FORK

U09P21301001

$75.53

12

INTERMEDIATE SUPPORT SEAT

U01P21400001

$73.71

13

HEXAGON FLANGE BOLTM10×1.25×25

GBT005789026

$0.91

14

FRONT DRIVE SHAFT MIDDLE SECTION ASSY

S03P21200002

$135.59

15

DRIVE SHAFT REAR SECTION COMPONENTS

S05P21300002

$301.21

16

RL CV DRIVE SHAFT ASSY(WIDE)

S05P14000002

$425.88

17

REAR LEFT INNER CV BOOT ASSEMBLY

S05P14001001

$162.89

17.1

CIRCLIP (2)

U09P13006001

$2.73

18

RL&RR CV BOOT DUST COVER ASSEMBLY

S05P13003001

$48.23

18.1

BIG CLAMPING BAND (3)

U09P13002001

$3.64

18.2

SMALL CLAMPING BAND (3)

U09P13004001

$2.73

19

REAR LEFT MIDDLE SHAFT_WIDE

S05P14003002

$101.92

20

RL&RL OUTER CV BOOT ASSEMBLY

S05P14002001

$170.17

21

RR CV DRIVE SHAFT ASSY(WIDE)

S05P13000002

$424.06

22

REAR RIGHT INNER CV BOOT ASSEMBLY

S05P13001001

$162.89

23

REAR RIGHT MIDDLE SHAFT_WIDE

S05P13002002

$109.20

24

CIRCLIP 30

GBT000894012

$0.91
