TRANSMISSION SHAFT AND GEAR SHIFT PARTS

TRANSMISSION SHAFT AND GEAR SHIFT PARTS

#

Item Name

Price

Qty

1

TRANSMISSION MAIN SHAFT

E01-F201010-000-01

$92.82

2

IDLE SHAFT ASSEMBLY

F01F20300001

$109.20

3

IDLE SHAFT

F01F20301001

$39.13

4

NEEDLE ROLLER BEARING K252913

F01F20310001

$2.73

5

R IDLE GEAR

F01F20302001

$26.39

6

SPACER 17×38×2

F01F20304001

$0.91

7

TRANSMISSION COUNTERSHAFT ASSEMBLY

F01F20600001

$387.66

9

CIRCLIP 25×1.2

F01F20216001

$0.91

10

REDUCTION DRIVEN GEAR

E01-F202020-000-00

$54.60

12

DRIVE BEVEL GEAR SEAT

F01-F004020-000-00

$31.85

13

BOLT M8×30

F01000015001

$1.82

14

Deep groove ball bearing 6328P5C3_63/28

BG002760-63028-001

$25.48

15

SHIM 0.2

E01-F201002-Z01-00

$0.91

15

SHIM 0.2 (2)

E01-F201002-Z02-00

$0.91

15

SHIM 0.2 (3)

E01-F201002-Z03-00

$0.91

15

SHIM 0.2 (4)

E01-F201002-Z04-00

$0.91

16

BEARING HUSING PLATE

F01F20404001

$0.91

17.1

DRIVE BEVEL GEAR

F01-F004010-000-00

N/A

-

17.2

DRIVEN BEVEL GEAR

F01-F004010-000-00

N/A

-

18

SCREW M8×25

GBT026731001

$0.91

19

NUT M22×1

F01F20403001

$3.64

20

BOLT M12×1.25×30

GBT005789054

$2.73

21

SPACER 12.5×32×5

F01F20509001

$1.82

22

O-RING 20×2.65

F01F20508001

$0.91

23

TRANSMISSION SHAFT FLANGE

F01F20507001

$50.96

24

OIL SEAL 44×60×7

F01F20503001

$12.74

25

BOLT M8×35

F01000016001

$1.82

26

DRIVEN BEVEL GEAR HOUSING

F01F20502001

$40.95

27

DRIVEN BEVEL GEAR SHIMS(0.2)

F01F20505001

$1.82

27

DRIVEN BEVEL GEAR SHIMS(0.3)

F01F20505003

$1.82

27

DRIVEN BEVEL GEAR SHIMS(0.4)

F01F20505004

$1.82

27

DRIVEN BEVEL GEAR SHIMS(0.5)

F01F20505005

$1.82

28

O-RING 88×2.8

F01F20504001

$3.64

29

NUT M65×1.5×8-LH

F01F20506001

$7.28

30

BEARING 6207

GBT000276010

$25.86

31

NUT M55×1.5×6-LH

F01C10001001

$6.37

32

BEARING 6205

GBT000276008

$11.83

33

TRANSMISSION SHAFT

F01F20601001

$79.17

34

BOLT M6×20

F01000013001

$0.91

35

GEAR SENSOR

F01F10700001

$35.46

36

O-RING 29.6×2.4

F01F10008001

$0.91

37

PARKING BRAKE SPRING PLUG

F01F10004001

$3.64

38

GASKET 14×21×1.5

F01F10003001

$0.91

39

PARKING BRAKE ARM SPRING

F01F10002001

$0.91

40

PARKING BRAKE PIN

F01F10005001

$2.73

41

SHIFT DRUM

F01F10100001

$63.70

42

BALL 3/8

GBT003081003

$0.91

43

NEUTRAL POSITION SPRING

E02-F100000-000-00

$0.91

44

NEUTRAL POSITION SPRING PLUG

F01F10007001

$3.16

45

POSITIONING STAR

F01F10402001

$8.00

46

SECTOR GEAR SPACER

F01F10405001

$5.46

47

SECTOR GEAR

F01F10403001

$12.26

48

SECTOR GEAR TORSION SPRING

F01F10404001

$1.03

49

SPACER 6.2×22×2

F01F10407001

$0.91

50

BOLT M6×40

F01F10406001

$0.91

51

SHIFTSHAFT COVER GASKET

F01F10010001

$0.91

52

SHIFTSHAFT COVER

F01F10009001

$54.35

53

BOLT M6×20 (2)

F01000004001

$0.91

54

OIL SEAL 15×25×5

F01F10011001

$3.81

55

SHIFT SHAFT

F01F10500001

$28.64

60

CIRCLIP 12

GBT000894006

$0.91

61

SHIFT FORK SPRING SEAT

F01F10203001

$1.81

62

SHIFT FORK

E02-F102000-000-00

$0.91

63

SHIFT FORK L

F01F10210001

$31.85

64

SHIFT RAIL L

E01-F102010-000-01

$10.01

65

SHIFT RAIL H/R ASSEMBLY

F01F10300001

$119.21

66

SHIFT FORK H/R

F01F10310001

$30.03

67

SHIFT RAIL H/R

F01F10301001

$5.46

68

PARKING BRAKE ARM

F01F10602001

$32.76

69

SPACER 12×20×1

F01F10603001

$0.91

70

PARKING BRAKE ARM SHAFT

F01F10601001

$4.55

71

PARKING BRAKE ARM ASSEMBLY

F01F10600001

$55.51
