Transmission components

Transmission components

#

Item Name

Price

Qty

1

NUT M30×1.5

E02F24007001

$7.00

2

Four-axis assembly

E02F24005001

$206.00

4

DRIVE GEAR ADJUSTMENT PAD 42×48×0.6

E02F24004003

$1.00

5

DRIVING BEVEL GEAR

E02F24001002

$150.00

6

BEARING 6305

GBT000276020

$79.00

7

NUT M30×1.5-LH

E02F24006001

$7.00

8

DRIVEN BEVEL GEAR SHAFT ENCLOSURE

E02F26003001

$2.00

9

BEARING 6206

GBT000276009

$38.00

10

DRIVEN GEAR ADJUSTMENT PAD 35×48×0.5

E02F26002003

$1.00

11

BEARING 6207

GBT000276010

$30.00

12

DRIVEN BEVEL GEAR SHAFT

E02F26001002

$226.00

13

Three-axis assembly

E02F23000001

$166.00

16

NEEDLE ROLLER P4×29.8

GBT000309003

$1.00

17

CIRCLIP 28×2.5

E02F22012002

$1.00

18

WASHER 28×40×2.5

E02F22008002

$2.00

19

L GEAR DRIVEN BEVEL

E02F22003001

$43.00

20

NEEDLE ROLLER BEARING K28×33×17

E02F22013002

$7.00

21

R/L GEAR COUPLING SLEEVE

E02F22006001

$28.00

22

CIRCLIP 35×2.5

D01P21207001

$2.00

23

SPACER 35×46×1.5

E02F22009001

$2.00

24

R GEAR DRIVEN BEVEL

E02F22004001

$50.00

25

NEEDLE ROLLER BEARING K35×40×13

E02F22011001

$8.00

26

COUNTERSHAFT

E02F22001001

$129.00

27

H GEAR ENGAGEMENT SLEEVE

E02F22007001

$27.00

28

H GEAR DRIVEN GEAR

E02F22002001

$52.00

29

PARKING GEAR

E02F22005001

$31.00

30

NUT M22×1

F01F20403001

$4.00

31

MAIN SHAFT (SSV)

E02F21000001

$155.00

32

WASHER 26×44×3

E02F27003001

$2.00

33

REVERSE GEAR IDLER

E02F27002001

$43.00

34

NEEDLE BEARING K30×35×17

E02F22010001

$7.00

35

REVERSE GEAR IDLER SHAFT

E02F27001001

$37.00

36

DOWEL PIN 6×10

GBT001192001

$1.00

37

DEEP GROOVE BALL BEARINGS 6211

GBT000276025

$64.00

38

REAR AXLE OUTPUT GEAR

E02F25001001

$190.00

39

O-RING SEAL 31×2.5

E02E10003001

$1.00

40

CVT DRIVEN WHEEL BUSHING

E02E10002001

$10.00
