Steering system,wide version

Steering system,wide version

#

Item Name

Price

Qty

1

HANDLEBAR

A03F16600001

$10.01

2

HANDLEBAR TUBE

A12-F165001-FB0-00

$39.13

3

HEXAGON SOCKET HEAD CAP SCREW M8×45

GBT000701024

$0.91

4

HANDLEBAR UPPER COVER

A03F16300001

$10.01

5

HANDLEBAR LOWER COVER

A03F16400001

$10.01

6

EPS STEERING COLUMN

A12-F131001-000-00

$126.49

7

STEERING SPHERE

A03F16200001

$3.64

8

LOCKING PLATE SPHERE

A03F16100001

$3.64

9

HARNESS STORAGE WIRE

A03F16101001

$1.82

10

HEXAGON FLANGE BOLT M8×16

GBT005789014

$0.91

11

WASHER 8

GB0000093004

$0.91

12

BOLT M8×35

A03F11001101

$0.91

13

EPS(TI)

A02F13100004

$2,408.77

14

HEXAGON FLANGE BOLT M10×1.25×20

GBT005789025

$0.91

15

STEERING ARM

A12-F110020-000-00

$39.13

16

1-HEXAGON SLOTTED NUT M10

GBT009457001

$2.73

17

STEERING ARM GASKET

T02000004001

$2.73

18

COTTER PIN 2.5 X 25

GBT000091006

$0.91

19

STEERING ROD

A12-F102001-000-00

$64.61

20

HANDLE TUBE GASKET

T02000006101

$1.82

21

BOLT M8×25

T03000008003

$2.73

22

STRAP

A03F16601001

$0.91
