STEERING SYSTEM NO-EPS

STEERING SYSTEM NO-EPS

#

Item Name

Price

Qty

1

HANDLEBAR

A03F16600001

$10.01

2

HEXAGON SOCKET HEAD CAP SCREW M8×45

GBT000701024

$0.91

3

TUBE-HANDLEBAR

A03F16500003

$85.54

4

COVER HANDLEBAR UPPER

A03F16300001

$10.01

5

COVER HANDLEBAR LOWER

A03F16400001

$10.01

6

NON-EPS STEERING SHAFT

A03F15000001

$100.10

7

STEERING SPHERE

A01-F162001-000-00

$3.64

8

LOCKING PLATE SPHERE

A03F16100001

$3.64

9

HEXAGON FLANGE BOLT M8×16

GBT005789014

$0.91

10

BOLT M8×25

GBT005789016

$0.91

11

HOLE WITH ELASTIC RETAINER 42

GBT000893001

$0.91

12

JOINT BEARING GE25ES-2RS

GBT000304001

$18.20

13

JOINT BEARING HOUSING

A01F12000002

$65.52

14

NON-METALLIC HEXAGON FLANGE NUT M8

GBT061831003

$0.91

15

COTTER PIN 2.5 X 25

GBT000091006

$0.91

16

1-HEXAGON SLOTTED NUT M10

GBT009459001

$1.82

17

STEERING ARM

A03F11001001

$46.41

18

HEXAGON FLANGE BOLT M8×30

GBT005789017

$0.91

19

STEERING ARM GASKET

T02000004001

$2.73

20

STEERING ROD ASSEMBLY

A03F12100001

$64.61
