ROOF AND EXTERNAL PLASTIC PARTS Plastic parts on the outside of the ceiling

ROOF AND EXTERNAL PLASTIC PARTS Plastic parts on the outside of the ceiling

#

Item Name

Price

Qty

1

CEILING(TAIL)

U06-H150201-0B0-00

$68.25

2

HEXAGON SOCKET MUSHROOM HEAD SCREW

T03000007002

$0.91

3

M6 NUT CLAMP

T04000002001

$0.91

4

CEILING SIDE SEALING STRIP(FRONT)

U06-H250102-0B0-00

$2.73

5

CEILING

U06-H150101-0B0-00

$278.46

6

Bolt M6×30

T03000007005

$1.82

7

LEFT COVER OF TOP BEAM

U06-H120701-0B0-00

$14.56

8

ROOF INNER COVER CLAMP

U09-H101004-0B0-01

$0.91

9

ROOF LEFT INNER COVER

U09-H101001-0B0-01

$3.64

10

LEFT SIDE COVER REAR SECTION

U06-H120501-0B0-00

$40.95

11

FRONT SECTION OF LEFT COVER

U06-H120301-0B0-00

$15.47

12

LEFT FOOT GUARD

U06-H120101-0B0-00

$3.64

13

U-SHAPED PLATEN 2

U03-H113801-0B0-00

$3.64

14

LARGE PAN HEAD HEX SOCKET BOLT M6×20

T03000007001

$0.91

15

ROOF RIGHT INNER COVER

U09-H101002-0B0-01

$3.64

16

FRONT SECTION OF RIGHT COVER

U06-H120401-0B0-00

$15.47

17

RIGHT FOOT GUARD

U06-H120201-0B0-00

$3.64

18

BOLT M6×16

GBT005789007

$0.91

19

WASHER

U01R10001001

$0.91

20

RIGHT SIDE COVER REAR SECTION

U06-H120601-0B0-00

$40.04

21

RIGHT COVER OF TOP BEAM

U06-H120801-0B0-00

$15.47
