Rear right iron door first generation

Rear right iron door first generation

#

Item Name

Price

Qty

1

RIGHT REAR DOOR FRAME

U03-C422000-FB0-00

$377.65

2

Type 1 Hexagon Nut M8

GBT006170004

$0.91

3

REAR DOOR LOWER RUBBER BLOCK

U03-H240103-0B0-00

$18.20

4

REAR DOOR LOCK

U03-C400021-W00-01

$10.92

5

HEXAGON FLANGE BOLT M8×30

GBT005789017

$0.91

6

RIGHT DOOR LOCK ASSEMBLY

U03-C452000-000-00

$47.32

7

HEXAGON SOCKET LARGE PAN HEAD BOLT M6×16

T03000007002

$0.91

9

REAR DOOR PAD

U03-H240102-0B0-00

$1.82

10

U01 BOLT M6

U01F10001001

$0.91

11

DOOR CABLE

U03-C456000-000-00

$8.19

12

NUT M8

GBT061831003

$0.91

13

CABLE SUPPORT ASSEMBLY

U03-C457100-DB0-00

$8.19

14

REAR RIGHT LOWER LATCH

U03-C439001-000-00

$59.15

15

REAR RIGHT UPPER LATCH

U03-C438001-000-00

$60.06

16

WASHER 8

GBT000971001

$0.91

17

HEXAGON FLANGE BOLT M8×20

GBT005789131

$0.91

18

BOLT M8×35

T03000008001

$2.73

19

BOLT M8×35 (2)

T03000008001

$2.73
