Item Name
Price
Qty
1
BOLT M8×90
F02C11004001
$2.73
2
Solenoid valve
E03-F302010-000-00
$106.47
3
SCREW PLUG M14
F02C10008001
4
O-RING 13.8×2.5
F01G00005001
$0.91
5
OIL SEAL 15×25×5
F01F10011001
$3.81
6
BREATHING JOINT
Q01F41300001
$12.65
7
BOLT M6×25
F01000005001
8
HOSE CLAMP
F01H00011001
$1.82
9
OIL PUMP COVER
E03-F302004-000-00
$22.75
10
INNER GEROTOR
D01P21402001
11
OUTER GEROTOR
D01P21403001
$3.64
12
NEEDLE ROLLER 4×15.8
GBT000309001
13
OIL PUMP SHAFT
E03-F302005-000-00
$10.92
14
NEEDLE ROLLER BEARING HK1516
GBT012764003
$5.46
15
Oil seal 35 × 52 × 7/11
E03-F301006-000-00
$12.74
16
GEAR SHIFT COVER GASKET
E03-F302007-000-00
17
O RING 15.6X1.78
E03-H002020-000-01
18
DIFFERENTIAL SHIFT FORK SHAFT
E03-F250000-000-00
$32.76
19
RIGHT GEARBOX
E03-F302001-000-00
$513.24
20
BEARING 6305
GBT000276012
$23.66
21
Needle roller P4 × 23.8
E03-F302011-000-00
22
BEARING 6206
GBT000276009
$32.94
23
STRAINER FILTER
E02F00100001
24
SCREW PLUG M14 (2)
F01G00201001
25
RETURN SPRING
E03-F250001-000-00
26
DIFFERENTIAL SHIFT FORK
E03-F250060-000-00
$29.12
27
BEARING 6010
BG002760-06010-001
$44.59
28
REAR DIFFERENTIAL OUTPUT SHIFT SLEEVE
E03-F205003-000-00
$46.41
29
DIFFERENTIAL HOUSING
E03-F205002-000-00
$131.04
30
PIN 4 × 35
BG008791-40035-001
31
SHIM Φ 40.2 ×Φ 50
Q02-R301007-000-00
32
RIGHT REAR HALF SHAFT BEVEL GEAR
E03-F205004-000-00
33
TRANSMISSION PLANETARY GEAR
E03-F205007-000-00
$20.93
34
BOWL SHAPED GASKET
Q02-R301014-000-00
35
REAR OUTPUT PLANETARY GEAR SHAFT
E03-F205006-000-00
36
LEFT REAR HALF SHAFT BEVEL GEAR
E03-F205010-000-00
$74.62
37
REAR OUTPUT GEAR
E03-F205001-000-00
$256.62
38
BOLT M10×1.25×25
GBT005789026
39
BEARING 61912
GBT000276035
$53.69
40
BEARING 6207
GBT000276010
$25.86
41
FRONT BEARING PRESSURE PLATE
E03-F301002-000-00
42
BOLT M6×16
F01000002001
43
AT10 LEFT GEARBOX
E03-F301401-000-00
$319.41
44
NUT M10X1.25
E02C00002001
45
OIL WINDOW
E02-C110007-000-01
46
OIL SEAL 30 × 55 × 7
E03-F301005-000-00
$8.19
47
O RING 73×3.0
E01-C102020-000-01
48
FRONT NUT COVER PLATE
E03-F301003-000-00
$16.38
49
BOLT M6×30
F01000006001
50
CLIP 30
BG008930-03000-F01
51
BOLT M8×70
F01000018001
52
O-RING 19.4×2.3
Q02F00007001
53
VEHICLE SPEED SENSOR
Q01F50300002
$58.24
54
SHIFT SHAFT
F01F10500001
$28.64
55
NEEDLE ROLLER BEARING HK121612
GBT012764001
56
HEXAGON HEAD BOLT M6×40
F01F10406001
57
SPACER 6.2×22×2
F01F10407001
58
SECTOR GEAR TORSION SPRING
F01F10404001
$1.03
59
SECTOR GEAR
F01F10403001
$12.26
60
SECTOR GEAR SPACER
F01F10405001
61
POSITIONING STAR
F01F10402001
$8.00
62
SPACER 15×28×1
F01G00008001
63
VARIABLE SPEED DRUM
E03-F110000-000-00
$59.15
64
NEUTRAL POSITION SPRING PLUG
F01F10007001
$3.16
65
GASKET 14×21×1.5
F01F10003001
66
NEUTRAL POSITION SPRING
F01F10001001
67
BALL 3/8
GBT003081003
68
GEAR SENSOR
F01F10700001
$35.46
69
O-RING 29.6×2.4
F01F10008001
70
BOLT M6×20
F01000004001
71
SHOULDER BOLT
F01F10408001
72
DETENT PAWL
F01F10401001
73
DETENT PAWL TORSION SPRING
F01F10006001
$1.22
74
CIRCLIP 12
GBT000894006
75
SHIFT FORK SPRING SEAT
F01F10203001
$1.81
76
SHIFT FORK
F01F10202001
77
L-GEAR FORK
E02F12101001
$30.94
78
L-GEAR SHIFT FORK SHAFT
E03-F120000-000-00
79
HR SHIFT FORK SHAFT
E03-F120001-000-00
80
H/R GEAR SHIFT FORK
E02F13101001
81
PARKING ARM RETURN SPRING
E03-F140050-000-00
82
SPACER 12×20×1
F01F10603001
83
PARKING ARM
E03-F140000-000-00
84
PARKING ARM SHAFT
E03-F120002-000-00
85
2/4 WD FORK
E03-F131000-000-00
$26.39
86
2/4 WD FORK SHAFT
E03-F120003-000-00
87
PARKING RATCHET
E03-F202005-000-00
$25.48
88
CIRCLIP 28×2.5
E02F22012002
89
WASHER 28×40×2.5
E02F22008002
90
H-GEAR DRIVEN GEAR
E03-F202004-000-00
91
NEEDLE ROLLER BEARING K28×33×17
E02F22013002
92
H GEAR ENGAGEMENT SLEEVE
E02F22007001
93
COUNTERSHAFT
E03-F202001-000-00
$109.20
94
NEEDLE ROLLER BEARING K35×40×13
E02F22011001
$6.37
95
R GEAR DRIVEN GEAR
E03-F202003-000-00
$40.95
96
SPACER 35×46×1.5
E02F22009001
97
CIRCLIP 35×2.5
D01P21207001
98
R/L GEAR COUPLING SLEEVE
E02F22006001
99
L GEAR DRIVEN GEAR
E03-F202002-000-00
$39.13
100
WASHERS 25 × 38 × 2.5
E03-F202007-000-00
