REAR AXLE DIFFERENTIAL WITH REAR DIFF

REAR AXLE DIFFERENTIAL WITH REAR DIFF

#

Item Name

Price

Qty

1

HEXAGON FLANGE BOLT M8×25

Q01F40201001

$1.82

2

OIL SEAL 30×45×6.5

Q03F40700001

$8.19

3

PLUG M18×1.5

Q02F00008001

$3.64

4

O-RING 16.4×2.5

Q02F00009001

$0.91

5

REAR AXLE BOX COVER

Q02-R401015-000-00

$72.80

6

O-RING  Φ 153 ×Φ 2.5

Q02-R401025-000-00

$2.73

7

BEARING 6011

BG002760-6011Z-001

$35.49

8

SHIM Φ 55 ×Φ 65 × (0.7, 0.6, 0.5)

Q02-R401021-000-00

$1.82

9

SCREW M10 × 1.25 × 16

Q02-R301021-000-00

$1.82

10

DRIVE AND DRIVEN BEVEL GEAR (450)

Q02-R102003-000-00

$292.11

11

HALF SHAFT BEVEL GEAR GASKET

Q02-R301017-000-00

$0.91

12

HALF SHAFT BEVEL GEAR

Q02-R301016-000-00

$12.74

13

PLANETARY GEAR SHAFT

Q02-R301018-000-00

$10.01

14

PLANETARY GEAR

Q02-R301015-000-00

$8.19

15

BOWL SHAPED GASKET

Q02-R301014-000-00

$0.91

16

PIN 4 × 35

BG008791-40035-001

$0.91

17

DIFFERENTIAL HOUSING

Q02-R301013-000-00

$111.02

18

SHIM Φ 50 ×Φ 55 × (0.7, 0.6, 0.5)

Q02-R401020-000-00

$1.82

19

BALL BEARING 61910

BG002760-61910-001

$36.40

20

BEARING RING

Q02-R401017-000-00

$20.93

21

CLUTCH TRANSMISSION PAWL

Q02-R301019-000-00

$33.67

22

RESET SPRING

Q02-R401019-000-00

$0.91

23

SHIFT FORK

Q02-R301020-000-00

$18.20

24

SUPPORT BRACKET

Q02-R401009-000-00

$17.29

25

U-SHAPED SPRING

Q02-R401011-000-00

$5.46

26

SHIFT FORK SHAFT SLEEVE

Q02-R401008-000-00

$6.37

27

SEALING RING

Q02-R401012-000-00

$0.91

28

SHIFT FORK PIN

Q02-R401007-000-00

$4.55

29

SOLENOID VALVE ASSEMBLY

Q01R50200001

$115.57

30

CIRCLIP 55

BG008930-55000-F01

$0.91

31

BALL BEARING 16006

BG002760-16006-001

$10.01

32

O-RING 13×1.5

Q02F00006001

$0.91

33

PLUG M14×1.5×11

Q02F00014001

$7.28

34

PIPE 600

Q02F00005001

$10.01

35

CLAMP 11

QCT006211003

$2.59

36

BREATHING CONNECTOR

Q03F40800001

$1.82

37

REAR AXLE BOX

Q02-R401016-000-00

$202.02

38

TAPERED ROLLER BEARING 32006

GBT000297001

$30.94

39

SPACER SLEEVE

Q02-R101019-000-00

$4.55

40

REAR AXLE DRIVE GEAR GASKET

Q02-R101020-000-00

$0.91

41

THREADED SLEEVE M30 × 1.5

Q02-R101021-000-00

$15.47

42

O-RING SEAL Φ 1.9 ×Φ 23.5

Q02-R101026-000-00

$0.91

43

OIL SEAL 48×65×9

Q02F00004001

$12.74

44

CIRCLIP 22

BG008930-22000-F01

$0.91

45

UNIVERSAL JOINT FORK

Q02-R101022-000-00

$60.06

46

WASHER Φ14.5×Φ35.2×4

Q02-R101007-000-00

$3.64

47

BOLT M14 ×1.5 × 30

Q02-R101025-000-00

$4.55

48

UNIVERSAL JOINT FORK 2

Q02-R101027-000-00

$69.16

49

450 REAR AXLE DIFFERENTIAL(WITH DIFF)

Q02-R000000-000-00

$1,758.12
