Left crankcase cover sub-assembly

Left crankcase cover sub-assembly

#

Item Name

Price

Qty

1

LEFT CRANKCASE COVER GASKET

E02C20001001

$8.19

2

BOLT M6×35

F01000007001

$0.98

3

MAGNETO STATOR ASSEMBLY

E02-C311000-000-00

$470.47

4

STEEL BELT ELASTIC HOSE CLAMP22

QCT006211009

$2.91

5

OIL COOLER INLET PIPE

F02C20004001

$9.10

6

BOLT M6×12

F01000001001

$0.91

7

HOSE CLAMP

F01H00002001

$0.91

8

A TYPE WORM DRIVE HOSE HOOP 50

QCT000620004

$1.82

9

WATER PUMP OUTLET PIPE

F02C20005001

$9.10

10

OIL FILTER

E02-G005000-000-00

$10.92

11

OIL FILTER ADAPTER

F01G00001001

$5.46

12

DOWEL PIN 6×10

GBT001192001

$0.91

13

WATER PIPE ADAPTER

F01H00008001

$6.71

14

MAGNETO CRIMPING PLATE

E02C20105001

$1.82

15

CIRCLIPS 26

GBT000893005

$0.91

16

BEARINGS 629-2RS

GBT000276027

$5.46

17

BOLT M6×20

F01000004001

$0.91

18

CRANK POSITION SENSOR (CPS)

E01K00300001

$55.90

19

O-RING 17×2

F01K00301001

$0.91

21

BOLT M6×25

F01000005001

$0.91

22

SENSOR WIRE CLAMP

F01K00003001

$0.91

23

STATOR COVER PLUG

E01C20104001

$19.41

24

O-RING 35×3.5

E01C20107001

$1.82

25

BOLT M6×55

F01000009001

$1.82

26

LEFT CRANKCASE COVER ASSEMBLY

E02-C201000-000-03

$176.54

27

OIL PASSAGE PLUG

E02C20003001

$6.37

28

GASKET 14×21×1.5

F01F10003001

$0.91
