Left crankcase cover sub-assembly

Left crankcase cover sub-assembly

#

Item Name

Price

Qty

1

LEFT CRANKCASE COVER GASKET

E02C20001001

$8.19

2

BOLT M6×35

F01000007001

$0.98

3

MAGNETO STATOR ASSEMBLY(680W)

E02C31100001

$172.90

4

STEEL BELT ELASTIC HOSE CLAMP 22

QCT006211009

$2.91

5

OIL COOLER INLET PIPE

F02C20004001

$9.10

6

BOLT M6×12

F01000001001

$0.91

7

HOSE CLAMP

F01H00002001

$0.91

8

A TYPE WORM DRIVE HOSE HOOP 50

QCT000620004

$1.82

9

WATER PUMP OUTLET PIPE

F02C20005001

$9.10

10

OIL FILTER

E02-G005000-000-00

$10.92

11

OIL FILTER ADAPTER

F01G00001001

$5.46

12

DOWEL PIN 6×10

GBT001192001

$0.91

13

WATER PIPE ADAPTER

F01H00008001

$6.71

14

MAGNETO CRIMPING PLATE

E02C20105001

$1.82

15

CIRCLIPS 26

GBT000893005

$0.91

16

BEARINGS 629-2RS

GBT000276027

$5.46

17

BOLT M6×20

F01000004001

$0.91

18

CRANK POSITION SENSOR (CPS)

E01K00300001

$55.90

19

O-RING 17×2

F01K00301001

$0.91

20

BOLT M6×25

F01000005001

$0.91

21

SENSOR WIRE CLAMP

F01K00003001

$0.91

22

STATOR COVER PLUG

E01C20104001

$19.41

23

O-RING 35×3.5

E01C20107001

$1.82

24

BOLT M6×55

F01000009001

$1.82

25

LEFT CRANKCASE COVER ASSY (UTV)

E02-C201000-000-03

$176.54

26

LEFT CRANKCASE COVER ASSEMBLY

E02C20100001

$170.17

27

OIL PASSAGE PLUG

E02C20003001

$6.37

28

GASKET 14×21×1.5

F01F10003001

$0.91

29

O-RING 58×2.65

E02-C201030-000-01

$1.82

30

BOLT M8×30

F01000015001

$1.82

31

OIL FILTER MOUNTING SEAT

E02-C201020-000-01

$66.43

32

O-RING 35×3.5 (2)

F01G00005001

$0.91

33

PLUG M14

F02C10008001

$2.73

34

BOLT M8×40

F01000017001

$1.82
