FUEL SYSTEM SHORT VERSION

FUEL SYSTEM SHORT VERSION

#

Item Name

Price

Qty

1

REAR FENDER HEAT SHIELD

A10-A500005-000-00

$25.48

2

HEAT SHIELD OF MIDDLE GUARD

A10-A500004-000-00

N/A

-

3

RING LA-5

GBT000961001

$0.91

4

SCREW ST4.2×16

GBT000845010

$0.91

5

HEXAGON FLANGE BOLT M6×30

GBT005789065

$0.91

6

T BUSHING

S01A50103001

$1.82

7

FUEL TANK RUBBER GASKET

S03A50106001

$1.82

8

AIR PIPE

A10-A500003-000-00

$4.55

9

CLAMP 11

QCT006211003

$2.59

10

BUFFER RUBBER SLEEVE

A10-A500001-000-00

$9.10

11

TANK INSTALL RUBBER SLEEVE

A01A51040001

$1.82

12

FUEL TANK

A10-A510000-000-00

$269.36

13

FUEL PUMP RETAINER RING

U01A51500001

$11.83

14

SCREW M6×16

T03000006002

$1.82

15

FUEL TANK HEAT SHIELD

A10-A500002-000-00

$22.75

16

CLAMP 16.5

T05000006001

$1.82

17

INJECTION PIPE

A10-A520002-000-00

$55.51

18

9.49QUICK-MOUNTING PLUG (90 DEGREE)

T07000001004

$10.01

19

FUEL FILTER

U01A52010001

$13.65

20

FUEL TANK COVER

A10-A500100-000-00

$16.38

21

FUEL PUMP PIPE

A10-A520001-000-00

$21.84

22

INJECTION PIPE ASSY

A10-A520000-000-00

N/A

-

23

FUEL PUMP

A10-M430000-000-00

$188.37
