FUEL SYSTEM EPA 50 STATE

FUEL SYSTEM EPA 50 STATE

#

Item Name

Price

Qty

1

BACK PANEL HEAT SHIELD

S10-A390003-000-00

$90.20

2

RING φ8×18

A10-A390001-000-00

$1.10

3

HEXAGON FLANGE BOLT M6×30

GBT005789065

$1.10

4

T BUSHING

S01A50103001

$2.20

5

TANK INSTALL RUBBER SLEEVE

A01A51040001

$2.20

6

FUEL TANK GASKET

S01A50106001

$4.40

7

FUEL TANK ASSEMBLY

S10-A510000-000-00

$353.00

8

FUEL TANK RUBBER GASKET

S03A50106001

$2.20

9

CLAMP 49

BQ006211-04912-001

$5.50

10

FUEL FILLER CONNECTION HOSE

S10-A500001-000-00

$81.40

11

FUEL FILLER

S01-A513000-000-01

$17.60

12

HEXAGON FLANGE BOLT M6×25

GBT005789010

$1.10

13

TANK COVER

S05-A510050-000-00

$17.60

14

CLAMP 22

QCT006211009

$4.40

15

ADSORPTION TUBE

S10-A530100-000-00

$64.90

16

FUEL TANK BREATHER

S10-A500002-000-00

$50.60

17

HEXAGON FLANGE BOLT M8×20

GBT005789015

$1.10

18

15.82 QUICK CONNECT PLUG

T07000001008

$13.20

19

CLAMP 23.5

T05000003002

$2.20

20

CARBON CANISTER VENT PIPE

S10-A530401-000-00

$50.60

21

REAR BREATHER

S10-A530403-000-00

$15.40

22

square elbow

S10-A530402-000-00

$2.20

23

CLAMP 26

QCT006211011

$4.40

24

CARBON CANISTER

S10-A531000-000-00

$106.00

25

DETACHMENT TUBE

S10-A530300-000-00

$103.40

26

CARBON CANISTER CONTROL VALVE

S10-A119229-000-00

$110.00

27

DETACHMENT TUBE (2)

S10-A530200-000-00

$48.40

28

FUEL PUMP

S10-M430000-000-00

$203.00

29

FUEL PUMP SEALING RING

U01A51400001

$35.20

30

FUEL PUMP RETAINER RING

U01A51500001

$15.40

31

FUEL PIPE, FUEL PUMP

S10-A520100-000-00

N/A

-

32

FUEL FILTER

S10-A520300-000-00

$24.57

33

FILTER SLEEVE

S10-A520001-000-00

$5.50

34

FUEL PIPE, ENGINE

S10-A520200-000-00

N/A

-

35

BOLT M6×16

GBT005789007

$1.10

36

CARGO HEAT SHIELD

S10-A390001-000-00

$198.00
