Fuel supply system 50 state

Fuel supply system 50 state

#

Item Name

Price

Qty

1

FUEL TANK GASKET

S01A50106001

$3.64

2

FUEL TANK (EPA)

U01A51100001

$308.49

3

FUEL TANK FRONT AND REAR SHOCK PAD

U01A50009001

$2.73

4

FUEL TANK UPPER SHOCK PAD

U01A50005001

$2.73

5

FUEL PUMP

U01M43000001

$225.68

6

FUEL PUMP SEALING RING

U01A51400001

$33.92

7

FUEL PUMP RETAINER RING

U01A51500001

$11.83

8

FUEL TANK HEAT-INSULATING FILM

U01A51305001

$2.73

9

HEAT-INSULATING FILM

U01-L900000-000-00

$5.46

10

WORM HOSE CLAMP(70)

QCT000620006

$2.73

11

CLAMP 16

QCT006211005

$2.73

12

FUEL FILLER BREATHER PIPE

U05A51400001

$36.44

13

FUEL FILLER PIPE

U01A51301001

$178.36

14

FUEL FILLER

U01A51302002

$20.02

15

M6 NUT CLAMP

T04000002001

$0.91

16

BOLT M6×16

T03000007002

$0.91

17

TANK COVER

S05-A510050-000-00

$12.74

18

CANISTER BRACKET

U05-A530090-DB0-00

N/A

-

19

HEXAGON FLANGE BOLT M6×16

GBT005789007

$0.91

20

CANISTER 45L

U05A53001001

$68.25

21

CLAMP 13

QCT006211004

$1.74

22

ADSORPTION PIPE

U05A53002001

$30.94

23

POSITIONING TIE Φ7×180

T05000001004

$0.91

24

SOLENOID VALVE INLET PIPE

U09A53003001

$24.57

25

CLAMP 13 (2)

QCT006211004

$1.74

26

CANISTER SOLENOID VALVE

A01M45000001

$67.34

27

SOLENOID VALVE OUTLET PIPE 1

U05-A530004-000-00

N/A

-

28

CLAMP 10

QCT006211020

$0.91

29

SOLENOID VALVE TUBE TEE

U05A53007001

$4.55

30

SOLENOID VALVE OUTLET PIPE 3

U05-A530006-000-00

$5.46

31

SOLENOID VALVE OUTLET PIPE 2

U05-A530005-000-00

$2.73

38

FUEL PIPE 1(NYLON)

U09A52001002

$39.13

39

U01 FUEL FILTER ASSY(PLUG-IN)

U01A52010002

$21.84

40

FUEL PIPE 2(NYLON)

U09A52003002

$39.13

41

FUEL INJECTION CIRCUIT (NYLON)

U09A52000002

$173.56
