Front suspension assembly (wide version) FRONT SUSPENSION ASSEMBLY (WIDE VEHICLE VERSION)

Front suspension assembly (wide version) FRONT SUSPENSION ASSEMBLY (WIDE VEHICLE VERSION)

#

Item Name

Price

Qty

1

RED FR LOWER A-ARM(WIDE VEHICLE VERSION)

S03-D106A00-FR0-01

$220.22

1

GREEN FR LOWER A-ARM(WIDE VERSION)

S03-D106A00-FG0-01

$220.22

1

BLACK FR LOWER A-ARM(WIDE VERSION)

S03-D106A00-FB0-01

$191.10

2

RIGHT KNUCKLE ASSEMBLY(WIDE VERSION)

S03D10200001

$250.25

2.1

RIGHT KNUCKLE(WIDE VEHICLE VERSION)

S03D10201001

$203.84

3

RED FR UPPER A-ARM(WIDE VEHICLE VERSION)

S03-D105A00-FR0-01

$250.25

3

GREEN FR UPPER A-ARM(WIDE VERSION)

S03-D105A00-FG0-01

$250.25

3

BLACK FR UPPER A-ARM(WIDE VERSION)

S03-D105A00-FB0-01

$250.25

4

FRONT SHOCK ABSORBER(RED,WIDE)

S03-D107000-0R0-01

$1,786.33

4

FRONT SHOCK ABSORBER (GREEN,WIDE)

S03-D107000-0G0-01

$1,786.33

4

FRONT SHOCK ABSORBER(BLACK,WIDE)

S03-D107000-0B0-01

$1,786.33

5

FRONT STABILIZER BAR ASSEMBLY

S01D108A0002

$70.98

6

FRONT BALANCE BAR BUFFER BLOCK

S01D10801001

$7.28

7

Rear balance bar mounting seat

U01D26002001

$23.66

8

FUEL CUP M6

GBT001152001

$0.91

8

90° joint type oil injection cup (taper thread)

T07000001007

$0.91

9

HEXAGON FLANGE BOLT M8×30

GBT005789017

$0.91

10

NUT M12×1.25

GBT061832002

$0.91

11

LEFT STABILIZER BALL JOINT

S01D10810001

$62.79

12

BOLT M12×1.25×95

GBT005789104

$3.64

13

SCREWS M8×25

GBT000701016

$0.91

14

BOLT M6×16

GBT005789007

$0.91

15

32 CLAMPS

T05000080002

$3.64

16

HEX FLANGE BOLT M12×1.25×75

GBT005789102

$3.64

17

2-NON-METALLIC HF NUT M10×1.25

GBT061832001

$0.91

18

LEFT KNUCKLE ASSEMBLY(WIDE VERSION)

S03D10100001

$250.25

18.1

LEFT KNUCKLE (WIDE VEHICLE VERSION)

S03D10101001

$203.84

18.2

HUB BEARING DAC30630342-2RSC1

JBT010238002

$56.42

18.3

RING,HOLE 63

GBT000893002

$0.91

19

BOLT M10×1.25×45

GBT005789030

$1.82

20

A-RING,SNAP

GBT000894004

$0.91

21

RED FL UPPER A-ARM (WIDE VERSION)

S03-D103A00-FR0-01

$250.25

21

GREEN FL UPPER A-ARM (WIDE VERSION)

S03-D103A00-FG0-01

$250.25

21

BLACK FL UPPER A-ARM (WIDE VERSION)

S03-D103A00-FB0-01

$250.25

22

KING PIN ASSEMBLY

S03D10301001

$37.31

23

NUT M12×1.25 (2)

GBT009459002

$1.82

24

COTTER 3.2×25

GBT000091008

$0.91

25

MAIN PIN

U01-D112010-000-00

$34.58

26

RED FL LOWER A-ARM(WIDE VEHICLE VERSION)

S03-D104A00-FR0-01

$220.22

26

GREEN FL LOWER A-ARM(WIDE VERSION)

S03-D104A00-FG0-01

$220.22

26

BLACK FL LOWER A-ARM(WIDE VERSION)

S03-D104A00-FB0-01

$220.22

27

FRONT LOWER A-ARM PLATE (BLACK)

S01C00001002

$22.82

28

ROCKER ARM DUST COVER 304

U09D20008001

$0.91

29

REAR ROCKER ARM LINER Ⅱ

U09D20006001

$3.55

30

FRONT ROCKER ARM LINER

U09D10001001

$4.55

31

BOLT M12×1.25×145

GBT005789106

$4.55

32

HEX FLANGE BOLT M12×1.25×320

S01D10900001

$11.83

33

FRONT UPPER A-ARM PLATE (BLACK)

S01-C010010-DB0-01

$18.20

34

RIGHT STABILIZER BALL JOINT

S01D10820001

$62.79

35

BOLT M12×1.25

GBT061872003

$0.91

36

FRONT DAMPER ASSEMBLY WIDE

S03-D107100-000-01

$1,249.43

37

JOINT BEARING COMBINATION RETAINING RING

S01-D107211-000-01

$0.91

38

SPHERICAL BEARING ASSEMBLY

S01-D107210-000-01

$25.48

39

FRONT DAMPER SPRING 1 RED WIDE

S03-D107221-PR0-01

$24.57

39

FRONT DAMPER SPRING 1 BLACK WIDE

S03-D107221-PG0-01

$24.57

39

FRONT DAMPER SPRING 1 GREEN WIDE

S03-D107221-PB0-01

$24.57

40

SPRING SPACER

S01-D107223-PB0-01

$9.10

41

FRONT DAMPER SPRING 2 RED WIDE

S03-D107222-PR0-01

$66.43

41

FRONT DAMPER SPRING 2 BLACK WIDE

S03-D107222-PG0-01

$66.43

41

FRONT DAMPER SPRING 2 GREEN WIDE

S03-D107222-PB0-01

$66.43

42

LOWER SPRING CUSHION

S01-D107224-PB0-01

$25.48
