FRONT AXLE DIFF

FRONT AXLE DIFF

#

Item Name

Price

Qty

1

BOLT M8×30

F01000015001

$1.82

2

OIL SEAL 24×38×8

Q02F00003001

$8.19

3

FRONT AXLE BOX COVER

Q02-F401000-000-00

$100.10

4

BOLT M8 × 12

Q02-F401002-000-00

$0.91

5

SHIFT FORK SHAFT

Q02-F301014-000-00

$2.73

6

FRONT AXLE SHIFT MOTOR ASSEMBLY

Q03F50100001

$203.84

7

BOLT M6×16

F01000002001

$0.91

8

O-RING 67.9×2.2

Q03F40300001

$1.82

9

SLIDING RACK

Q02-F301015-000-00

$7.28

10

SHIFT FORK

Q02-F301013-000-00

$11.83

11

AIR TAP

Q02F04103001

$4.55

12

CLAMP 11

QCT006211003

$2.59

13

PIPE 600

Q02F00005001

$10.01

14

BEARING 16007

GBT000276036

$15.47

15

CIRCLIP 62

GBT000893008

$1.82

16

OUTPUT SLEEVE

Q02-F301012-000-00

$30.94

17

COMBINATION SLEEVE

Q02-F301011-000-00

$37.31

18

WASHER

Q02F20007001

$0.91

19

BEARING 61912

GBT000276035

$53.69

20

SCREWS M8×20

GBT000701041

$0.91

21

DIFFERENTIAL COVER

Q02-F301001-000-00

$31.85

22

LEFT HALF SHAFT GEAR GASKET

Q02-F301010-000-00

$1.82

23

LEFT HALF SHAFT BEVEL GEAR

Q02-F301004-000-00

$18.20

24

PLANETARY GEAR GASKET

Q02-F301008-000-00

$0.91

25

PLANETARY GEAR

Q02-F301002-000-00

$10.01

26

PLANETARY SHAFT CARRIER

Q02-F301007-000-00

$10.01

27

PLANETARY GEAR SHAFT I

Q02-F301005-000-00

$7.28

28

PLANETARY GEAR SHAFT II

Q02-F301006-000-00

$7.28

29

RIGHT HALF SHAFT BEVEL GEAR

Q02-F301003-000-00

$18.20

30

RIGHT HALF SHAFT GEAR GASKET

Q02-F301009-000-00

$1.82

31

DIFFERENTIAL HOUSING

Q02-F301000-000-00

$52.78

32

DRIVE AND DRIVEN BEVEL GEAR(450)

Q02-F102000-000-00

$211.12

33

BEARING 61908

BG002760-61908-001

$14.56

34

BEVEL GEAR ADJUSTING WASHER

Q02F20003001

$0.91

35

HEXAGON FLANGE BOLT M8×25

Q01F40201001

$1.82

36

O-RING 19.4×2.3

Q02F00007001

$0.91

37

VEHICLE SPEED SENSOR

Q01F50300002

$58.24

38

PLUG M18×1.5

Q02F00008001

$3.64

39

O-RING 16.4×2.5

Q02F00009001

$0.91

40

O-RING 13×1.5

Q02F00006001

$0.91

41

PLUG M14×1.5×11

Q02F00014001

$7.28

42

FRONT AXLE BOX

Q02-F401001-000-00

$107.38

43

NEEDLE BEARING HK152112

Q02F40202001

$5.46

44

BEARING 6007

GBT000276037

$15.47

45

NUT M64 × 1.5

Q02-F401004-000-00

$15.47

46

O-RING 26 × 2.7

Q02-F101001-000-00

$1.82

47

OIL SEAL 48×65×9

Q02F00004001

$12.74

48

CIRCLIP 22

BG008930-22000-F01

$0.91

49

UNIVERSAL JOINT FORK 1

Q02-F101002-000-00

$66.43

50

WASHER Φ14.5×Φ35.2×4

Q02-R101007-000-00

$3.64

51

BOLT M14 ×1.5 × 30

Q02-R101025-000-00

$4.55

52

UNIVERSAL JOINT FORK 2

Q02-R101027-000-00

$69.16

53

450 FRONT AXLE ASSEMBLY

Q02-F000000-000-00

$1,607.97
