Front axle assembly FRONT AXLE

Front axle assembly FRONT AXLE

#

Item Name

Price

Qty

1

HEXAGON FLANGE BOLT M8×25

Q01F40201001

$1.82

2

OIL SEAL 38×55×7

D02P22202001

$12.74

3

BREATHING JOINT

Q01F41300001

$12.65

4

FRONT AXLE END COVER

Q03F40200002

$74.62

5

RECTANGULAR GASKET

Q01F40500001

$6.37

6

BEARING 16010

GBT000276038

$25.48

7

LIMITING LINER

Q01F40400001

$5.46

8

HEXAGON FLANGE BOLT M10×1.0×18

Q03F30800001

$1.82

9

DIFFERENTIAL COVER

Q03F30200001

$93.73

10

Axle shaft bevel gear gasket (0.8)

Q01R31600001

$1.82

10

Axle shaft bevel gear gasket (1)

Q01R31600002

$1.82

10

Axle shaft bevel gear gasket (1.2)

Q01R31600003

$1.82

11

Half Shaft Bevel Gear Ⅰ assembly

Q03F30600000

$85.54

12

Planetary gear shaft V

Q03F30300001

$15.47

13

Planetary gear liner

Q01R31700003

$2.78

14

Planetary gear

Q01R30900003

$27.92

15

Half shaft bevel gear II

Q03F30700001

$98.28

16

DIFFERENTIAL HOUSING

Q03F30100001

$203.84

17

DRIVE DRIVEN BEVEL GEAR KIT

Q01F10100000

$378.56

18

AXLE SHAFT ASSY

Q03F30900000

$75.53

19

COMBINATION SETS

Q03F31000001

$51.87

20

SPACER 40.2×50×3

Q03F31500001

$1.82

21

BUSHINGⅠ(Φ97)

Q01F41000001

$17.29

22

BEARING 16008

GBT000276015

$23.66

23

FRONT AXLE HOUSING

Q03F40100002

$194.74

24

BUSHINGⅡ(Φ15)

Q01F41100001

$4.55

25

DRIVE BEVEL GEAR SHIMS(0.3)

Q01F10200001

$2.73

25

DRIVE BEVEL GEAR SHIMS(0.4)

Q01F10200002

$2.73

25

DRIVE BEVEL GEAR SHIMS(0.5)

Q01F10200003

$2.73

25

DRIVE BEVEL GEAR SHIMS(0.6)

Q01F10200004

$2.73

25

DRIVE BEVEL GEAR SHIMS(0.7)

Q01F10200005

$2.73

26

BEARING 3306

GBT000296001

$80.99

27

CIRCLIP 30

GBT000894012

$0.91

28

NUT M75×1.5×6-LH

Q01F41200001

$10.92

29

Oil seal 30×45×6.5

Q03F40700001

$8.19

30

BOLT M6×16

F01000002001

$0.91

31

VEHICLE SPEED SENSOR ASSEMBLY

Q01F50300001

$63.70

32

O-RING 12×2

Q01F40900001

$0.91

33

PLUG M14

F02C10008001

$2.73

34

O-RING 13.8×2.5

F01G00005001

$0.91

35

ENGINE DRAIN PLUG M14

F01G00200001

$5.02

36

O-RING 67.9×2.2

Q03F40300001

$1.82

37

FRONT AXLE SHIFT MOTOR ASSEMBLY

Q03F50100001

$203.84

38

SHIFT FORK

Q03F31100001

$10.92

39

SLIDING RACK

Q03F31200001

$3.64

40

FORK SHAFT 5×65

Q03F31300001

$0.91

41

HEXAGON SCREW M8×8

Q03F31400001

$0.91

42

FRONT AXLE ASSY

Q03F00000002

$2,301.39
