1 1

Frame

Frame

#

Item Name

Price

Qty

1

HEXAGON FLANGE BOLT M8×16

GBT005789014

$1.00

2

HORN BRACKET

A12-C021000-DB0-00

$3.00

3

HEXAGON FLANGE BOLT M8×20

GBT005789015

$1.00

4

FRONT SHELF SUPPORT

A12-C003000-DB0-00

$151.00

5

BOLT M6×16

GBT005789007

$1.00

6

START RELAY BRACKET

A12-C009000-DB0-00

$4.00

7

RIGHT FOOT SUPPORT BRACKET

A12-C002000-DB0-00

$89.00

8

HEXAGON FLANGE BOLT M8×30

GBT005789017

$1.00

9

BOLT M10×1.25×25

GBT005789026

$1.00

10

RIGHT BAR

A12-C013000-DB0-00

$47.00

11

SEAT BRACKET

A12-C014000-DB0-00

$51.00

12

REAR SHELF SUPPORT

A12-C007000-DB0-00

$56.00

13

MUFFER LOWER SEAT

A12-C017000-DB0-00

N/A

-

14

HEXAGON FLANGE BOLT M6×12

GBT005789006

$1.00

15

NUT M6

GBT061831002

$1.00

16

REAR LICESNSE BRACKET

A12-C011000-DB0-00

$46.00

17

T3 REAR LICENSE

A02-N200010-DB0-00

$18.00

18

HITCH BALL

U01R21100001

$66.00

21

BALL SPRING WASHER

U01R21103001

$4.00

22

BALL NUT

U01R21102001

$9.00

23

TRAILER PIN

U01R21300001

$8.00

24

LEFT BAR

A12-C012000-DB0-00

$42.00

25

LEFT FOOT PEDAL BRACKET

A12-C001000-DB0-00

$89.00

26

RECTIFIER BRACKET

A12-C018000-DB0-00

$12.00

27

ABS MOUNTING BRACKET

A02-C000700-DB0-00

$7.00

28

HEXAGON FLANGE BOLT M10×1.25×20

GBT005789025

$1.00

29

HEXAGON FLANGE BOLT M10×1.25×16

GBT005789024

$1.00

30

LOCKING NUT M10

GBT006183001

$1.00

31

FRONT AXLE UPPER BRACKET

A12-C005000-DB0-00

$26.00

32

HEXAGON FLANGE BOLT M10×1.25×125

GBT005789042

$5.00

33

AT10 FRAME

A12-B010000-DB0-01

$2,895.00

34

BOLT M6×10

GBT005789005

$1.00

35

CARBON CANISTER BRACKET

A12-C008000-DB0-00

$7.00
