External plastic parts

External plastic parts

#

Item Name

Price

Qty

1

M6 NUT CLIP

T04000002001

$0.91

2

BOLT M6×20

T03000007001

$0.91

3

ROOF EMPENNAGE COVER PP BLACK

U01H13203001

$66.43

4

WASHER Φ6

GBT000961002

$1.87

5

NUT M6

GBT061831002

$0.91

6

ROOF COVER SEALING STRIP

U01H13205001

$3.64

7

FUEL FILLER BAFFLE

U01-H232030-0B0-01

$13.65

8

LEFT HANDLE SHIELD

U01-H143110-0B0-01

$15.47

9

LR SIDE PLATE COVER

U09-H123120-0B0-01

$34.58

9.1

LR SIDE PLATE COVER (2)

U09-H123120-0B0-00

$70.98

10

WASHER

U01R10001001

$0.91

11

BOLT M6×16

GBT005789007

$0.91

12

HEXAGON SOCKET MUSHROOM HEAD SCREW

T03000007002

$0.91

13

LF SIDE PLATE COVER PP BLACK

U01H12311001

$20.93

14

FRONT SKID PIATE

U09-H101001-0K0-00

$97.37

15

MIDDLE SKID PIATE

U09-H101002-0K0-00

$20.93

16

REAR SKID PLATE

U09-H101003-0B0-01

$101.92

17

ROOF LEFT INNER COVER

U09-H101001-0B0-01

$3.64

18

ROOF INNER COVER CLAMP

U09-H101004-0B0-01

$0.91

19

ROOF COVER PP BLACK

U01H13201001

$324.87

20

ROOF RUBBER RING

U01H13204001

$1.82

21

ROOF BUSH

T02000008001

$1.82

22

BOLT M8×35

T03000008001

$2.73

23

NON-METALLIC HEXAGON FLANGE NUT M8

GBT061831003

$0.91

24

LARGE WASHER A GRADE 8

GBT000961003

$0.91

25

BOLT M8×25

T03000008003

$2.73

26

ROOF RIGHT INNER COVER

U09-H101002-0B0-01

$3.64

27

RIGHT HANDLE SHIELD

U01-H142110-0B0-01

$15.47

28

RR INNER PLATE COVER

U01-H124130-0B0-00

$15.47

29

RR SIDE PLATE COVER

U09-H124120-0B0-01

$37.31

29.1

RR SIDE PLATE COVER PP BLACK

U09-H124120-0B0-00

$70.98

30

RF SIDE PLATE COVER PP BLACK

U01H12411001

$20.93

31

OIL FILLER COVER PP BLACK

U09-H127100-0B0-00

$10.92

32

CHARGING PORT COVER PP BLACK

U01H12810001

$14.56
