EXHASUT SYSTEM Exhaust system

EXHASUT SYSTEM Exhaust system

#

Item Name

Price

Qty

1

Oxygen Sensor

E01-K000002-000-00

$285.00

2

EXHUAST PIPE ASSY

S10-A310000-000-00

$419.00

3

SEALING GASKET

S10-A333000-000-00

$26.40

4

FRONT PIPE HEAT SHIELD

S10-A310100-000-00

$75.90

5

FRONT PIPE HEAT SHIELD (2)

S10-A360000-000-00

$94.60

6

EXHAUST PIPE INSTALLTION SPRING

A01A32005001

$9.90

7

EXHAUST PIPE BOLT

A01A32004001

$7.70

8

GRAPHITE SEALING SLEEVE

S10-A350000-000-00

$25.30

9

LOWER HEAT SHIELD

S10-A372000-000-00

N/A

-

13

UPPER HEAT SHIELD

S10-A371000-000-00

N/A

-

15

ENGINE UPPER DAMPING

S05-A380100-000-00

$18.70

15

LOWER MOUNTING SEAT

S01C02900002

$40.70

16

HEXAGON FLANGE BOLT M8×16

GBT005789014

$1.10

17

BOLT M6×16

GBT005789007

$1.10

18

Spring washer Φ 6

GB0000093003

$1.10

19

PLAIN WASHER 6

GBT000971002

$1.10

20

A-BAND, TRANSMISSION HOSE 80

QCT000620007

$3.30

21

BOLT M6×12

T03000014001

$1.10

22

MUFFLER

S10-A320000-000-00

$3,747.00

23

SUPPORT BLOCK

U06-A340000-000-00

$9.90
