Drive shaft assembly

Drive shaft assembly

#

Item Name

Price

Qty

1

BOLT M8×35

A03F11001101

$0.91

3

U09_FRONT TRANSMISSION SHAFT FRONT SECTION

U09P21100001

$314.86

3a

TRANSMISSION SHAFT MOUNTING SPLINE FORK

U01P21101001

$65.52

3b

UNIVERRSAL CROSS SHAFT ASSY

U01P22010001

$50.05

3c

CIRCLIP 25

GBT000893007

$2.73

4

INTERMEDIATE SUPPORT SEAT

U01P21400001

$73.71

5

BOLT M10×1.25×20

GBT005789025

$0.91

6

U09 REAR SECTION FRONT TRANSMISSION SHAFT

U09P21300001

$318.50

6a

GLIB M6

GBT001152001

$0.91

6b

TRANSMISSION SHAFT SLIDING SPLINE FORK

U09P21301001

$75.53

7

U01_CONSTANT VELOCITY DRIVE SHAFT FL

U01P11000001

$329.42

8

FL INNER BALL CAGE ASSY

U01P11030001

$121.03

8a

CIRCLIP

U01P11011001

$2.73

9

MAINTENANCE KIT FOR INNER BALL CAGE ASSY

U01P11040001

$42.77

9a

BIG CLAMPING BAND

U01P11008001

$3.64

9b

SMALL CLAMPING BAND

U01P11006001

$2.73

10

SHAFT

U01P11005001

$68.25

11

MAINTENANCE KIT FOR OUTSIDE BALL CAGE ASSY

U01P11050001

$29.12

11a

SMALL CLAMPING BAND (2)

U01P11004001

$2.73

11b

BIG CLAMPING BAND (2)

U01P11002001

$4.55

12

OUTSIDE BALL CAGE ASSY

U01P11020001

$119.21

13

U01_CONSTANT VELOCITY DRIVE SHAFT FR

U01P12000001

$328.51

14

FR INNER BALL CAGE ASSY

U01P12030001

$119.21

15

U09_CONSTANT VELOCITY DRIVE SHAFT RL

U09P14000001

$371.28

16

RL INNER BALL CAGE ASSY

U09P14020001

$40.95

16a

CIRCLIP (2)

U09P13006001

$2.73

17

MAINTENANCE KIT FOR REAR SHAFT ASSY

U09P13030001

$40.95

17a

BIG CLAMPING BAND (3)

U09P13002001

$3.64

17b

SMALL CLAMPING BAND (3)

U09P13004001

$2.73

18

RL SHAFT

U09P14005001

$74.62

19

OUTSIDE BALL CAGE ASSY (2)

U09P13010001

$127.40

20

U09_CONSTANT VELOCITY DRIVE SHAFT RR

U09P13000001

$373.10

21

RR SHAFT

U09P13005001

$74.62

22

RR INNER BALL CAGE ASSY

U09P13020001

$129.22
