CYLINDER AND CYLINDER HEAD Cylinder head cylinder block assembly

CYLINDER AND CYLINDER HEAD Cylinder head cylinder block assembly

#

Item Name

Price

Qty

1

OIL FILL CAP

F01A10004001

$3.64

2

OIL FILL CAP SEAL

F01A10005001

$3.61

3

O-RING 22×3

F01A10009001

$0.91

4

VALVE COVER BOLT

F01A10008001

$1.82

5

RUBBER ISLOATOR

F01A10003001

$1.82

6

VALVE COVER

F01A10001003

$39.13

7

CYLINDER HEAD BOLT

F01A20600001

$5.54

8

DOWEL PIN 10×14

F01A10007003

$0.91

9

CYLINDER HEAD COVER SEAL

F01A10002001

$30.03

10

BOLT M6×90

F01000012001

$1.94

11

STUD M8×43

F01A20008001

$0.91

12

HOSE CLAMP

F01H00011001

$1.82

14

O RING 48.8×2.6

U06-A270000-000-00

$1.82

15

INTAKE MANIFOLD

U06-A240000-000-00

$38.22

16

SCREWS M8×25

GBT000701016

$0.91

17

WORM HOSE CLAMP(70)

QCT000620006

$2.73

18

INLET MANIFOLD RUBBER SLEEVE

U06-A250000-000-00

$4.55

19

CYLINDER HEAD GASKET

E01-A302000-000-01

$21.84

20

DOWEL PIN 6X 10

GBT001192001

$0.91

21

TIMING CHAIN

F01A40400001

$167.18

22

CHAIN GUIDE

F01A40500001

$10.92

23

TIMING CHAIN TENSIONER

E02-A406010-000-02

$21.84

24

HEXAGON SOCKET PAN HEAD STEPPED BOLTS

F01A40007002

$1.82

25

BOLT M6×20

F01000004001

$0.91

26

CHAIN GUARD

F01A40005001

$4.55

27

BOLT M6×25

F01000005001

$0.91

28

PIPE+LINE FIXING PLATE

F01A40011001

$3.64

29

TENSIONER

E02-A403000-000-02

$30.94

30

TENSIONER GASKET

F01A40008001

$0.91

31

CYLINDER (Ⅰ)

F01A30100003

$146.51

31

CYLINDER (Ⅱ)

F01A30100004

$146.51

32

CYLINDER BASE GASKET

F01A30001001

$9.10
