2022 Cooling system assembly

2022 Cooling system assembly

#

Item Name

Price

Qty

1

BOLT M6×25

GBT005789010

$1.00

2

T BUSH V

U09A41105001

$2.00

3

I-SHAPED RUBBER RING V

U09A41104001

$3.00

4

RADIATOR MOUNTING BRACKET ASSY

U01C00010002

$14.00

5

BOLT M6×16

GBT005789007

$1.00

6

RADIATOR BODY V

U09A41101002

$466.00

7

T-SHAPED RUBBER RING V

U09A41103001

$3.00

8

FAN MOTOR ASSY V

U09A41102001

$196.00

9

HEXAGON FLANGE BOLT M6×20

GBT005789008

$3.00

10

CLAMP,SPRINGBAND 11

QCT006211003

$1.00

11

RADIATOR REGATIVE PRESSURE PIPE

U09A43051001

$6.00

12

WATER TANK BODY

U01A43041004

$28.00

13

M6 NUT CLIP

T04000002001

$1.00

14

CLAMP 38

QCT006211016

$5.00

14

CLAMP 38 (WIDE 15)

BQ006211-03815-Z01

$5.00

15

ENGINE FRONT WATER INLET HOSE

U09A42006001

$39.00

16

38 ADHESIVE STRIP CLAMP

T05000070001

$4.00

17

ENGINE FRONT WATER OUTLET HOSE

U09A42001001

$44.00

18

ENGINE WATER INLET AL PIPE

U09A42005001

$58.00

19

ENGINE WATER OUTLET AL PIPE

U09A42004001

$58.00

20

WATER PIPE CLAMP

U09A42011001

$1.00

21

ENGINE REAR WATER OUTLET HOSE

U09A42002001

$69.00

22

ENGINE OIL COOLING PIPE

U09A42008001

$10.00

23

CLAMP 20

QCT006211015

$3.00

24

ENGINE REAR WATER INLET HOSE 1

U09A42003001

$25.00

25

ENGINE RADIATOR THREE-WAY

S01A42500001

$13.00

26

ENGINE REAR WATER INLET HOSE 2

U09A42007002

$21.00

27

TANK LID ASSY V

A01A41110002

$11.00

34

WATER TANK COVER

U01A43042001

$3.00

35

WATER TANK PLUG

U01A43043001

$1.00

36

ENGINE RADIATOR ASSY(V)

U09A41100001

$700.00
